Cummins series diesel generator
Short Description:
Main features of MTU diesel generator sets: 1. V-shaped arrangement with a 90° angle, water-cooled four-stroke, exhaust gas turbocharged, and inter-cooled. 2. The 2000 series adopts electronically controlled unit injection, while the 4000 series uses a common rail injection system. 3. Advanced electronic management system (MDEC/ADEC), outstanding ECU alarm function, and a self-diagnostic system capable of detecting over 300 engine fault codes. 4. The 4000 series engines have an automatic cyli...
The Cummins series diesel generators are powered by engines of the B, N, and K series jointly developed by China and the United States. Their reliability and economy have always won the trust of military units, engineering, and industrial and mining enterprises. Cummins was founded in February 1919 and its headquarters is located in Columbus, Indiana, USA. Cummins has distribution and service outlets in 190 countries and regions around the world, covering 500+ distribution institutions. It provides reliable service guarantees for customers. As the largest foreign investor in the Chinese engine industry, Cummins has manufacturing enterprises in China such as Chongqing Cummins Engine Co., Ltd. (producing B, C, and L series) and Dongfeng Cummins Engine Co., Ltd. (producing M, N, and K series).
Technical parameters of Cummins diesel generator set:
|
机组型号 Unit Model |
输出功率 output power(kw) |
电流 current(A) |
柴油机型号 Diesel engine model |
缸数cylinders Qty. |
缸径*行程Cylinder diameter * Stroke（mm） |
排气量 gas displacement (L) |
燃油消耗率 fuel consumption rate g/kw.h |
机组尺寸 Unit size mm L×W×H |
机组重量 Unit weight kg |
|
|
KW |
KVA |
|||||||||
|
JHK-15GF |
15 |
18.75 |
27 |
4B3.9-G2 |
4 |
102*120 |
3.9 |
208 |
1650*720*1200 |
700 |
|
JHK-20GF |
20 |
25 |
36 |
4B3.9-G2 |
4 |
102*120 |
3.9 |
208 |
1650*720*1200 |
700 |
|
JHK-24GF |
24 |
30 |
43.2 |
4BT3.9-G2 |
4 |
102*120 |
3.9 |
208 |
1700*720*1200 |
710 |
|
JHK-30GF |
30 |
37.5 |
54 |
4BT3.9-G2 |
4 |
102*120 |
3.9 |
208 |
1700*720*1200 |
800 |
|
JHK-40GF |
40 |
50 |
72 |
4BTA3.9-G2 |
4 |
102*120 |
3.9 |
210 |
1800*750*1200 |
920 |
|
JHK-50GF |
50 |
62.5 |
90 |
4BTA3.9-G2 |
4 |
102*120 |
3.9 |
210 |
1800*750*1200 |
950 |
|
JHK-64GF |
64 |
80 |
115.2 |
4BTA3.9-G11 |
4 |
102*120 |
3.9 |
210 |
1850*800*1300 |
1000 |
|
JHK-80GF |
80 |
100 |
144 |
6BT5.9-G2 |
6 |
102*120 |
5.9 |
210 |
2250*800*1300 |
1250 |
|
JHK-100GF |
100 |
125 |
180 |
6BTA5.9-G2 |
6 |
102*120 |
5.9 |
207 |
2300*800*1300 |
1300 |
|
JHK-120GF |
120 |
150 |
216 |
6BTAA5.9-G2 |
6 |
102*120 |
5.9 |
207 |
2300*830*1300 |
1350 |
|
JHK-150GF |
150 |
187.5 |
270 |
6CTA8.3-G2 |
6 |
114*135 |
8.3 |
207 |
2400*970*1500 |
1600 |
|
JHK-180GF |
180 |
225 |
324 |
6CTAA8.3-G2 |
6 |
114*135 |
8.3 |
207 |
2400*970*1500 |
1700 |
|
JHK-200GF |
200 |
250 |
360 |
6LTAA8.9-G2 |
6 |
114*145 |
8.9 |
207 |
2600*970*1500 |
2000 |
|
JHK-220GF |
220 |
275 |
396 |
6LTAA8.9-G3 |
6 |
114*145 |
8.9 |
203 |
2600*970*1500 |
2000 |
|
JHK-320GF |
320 |
400 |
576 |
6ZTAA13-G3 |
6 |
114*145 |
13 |
202 |
2900*1200*1750 |
3000 |
|
JHK-400GF |
400 |
500 |
720 |
6ZTAA13-G4 |
6 |
114*145 |
13 |
202 |
2900*1200*1750 |
3000 |
|
JHK-400GF |
400 |
500 |
720 |
QSZ13-G2 |
6 |
130*163 |
13 |
201 |
3100*1250*1800 |
3100 |
|
JHK-450GF |
450 |
562.5 |
810 |
QSZ13-G3 |
6 |
130*163 |
13 |
201 |
3100*1250*1800 |
3100 |
|
JHK-200GF |
200 |
250 |
360 |
NT855-GA |
6 |
140*152 |
14 |
206 |
3000*1050*1750 |
2600 |
|
JHK-200GF |
200 |
250 |
360 |
MTA11-G2 |
6 |
140*152 |
14 |
206 |
3000*1050*1750 |
2700 |
|
JHK-250GF |
250 |
312.5 |
450 |
NTA855-G1A |
6 |
140*152 |
14 |
207 |
3100*1050*1750 |
2900 |
|
JHK-280GF |
280 |
350 |
504 |
MTAA11-G3 |
6 |
125*147 |
11 |
210 |
3100*1050*1750 |
2900 |
|
JHK-280GF |
280 |
350 |
504 |
NTA855-G1B |
6 |
140*152 |
14 |
206 |
3100*1050*1750 |
2950 |
|
JHK-300GF |
300 |
375 |
540 |
NTA855-G2A |
6 |
140*152 |
14 |
206 |
3200*1050*1750 |
3000 |
|
JHK-350GF |
350 |
437.5 |
630 |
NTAA855-G7A |
6 |
140*152 |
14 |
205 |
3300*1250*1850 |
3200 |
|
JHK-400GF |
400 |
500 |
720 |
KTA19-G3A |
6 |
159*159 |
19 |
206 |
3300*1400*1970 |
3700 |
|
JHK-450GF |
450 |
562.5 |
810 |
KTA19-G4 |
6 |
159*159 |
19 |
206 |
3300*1400*1970 |
3900 |
|
JHK-500GF |
500 |
625 |
900 |
KTA19-G8 |
6 |
159*159 |
19 |
206 |
3500*1500*2000 |
4200 |
|
JHK-550GF |
550 |
687.5 |
990 |
KTAA19-G6A |
6 |
159*159 |
19 |
206 |
3600*1500*2000 |
4800 |
|
JHK-600GF |
600 |
750 |
1080 |
KT38-GA |
12 |
159*159 |
38 |
206 |
4300*1700*2350 |
7000 |
|
JHK-650GF |
650 |
812.5 |
1170 |
KTA38-G2 |
12 |
159*159 |
38 |
206 |
4300*1700*2350 |
7500 |
|
JHK-700GF |
700 |
875 |
1260 |
KTA38-G2B |
12 |
159*159 |
38 |
206 |
4400*1750*2350 |
8000 |
|
JHK-800GF |
800 |
1000 |
1440 |
KTA38-G2A |
12 |
159*159 |
38 |
206 |
4500*1750*2350 |
8200 |
|
JHK-900GF |
900 |
1125 |
1620 |
KTA38-G5 |
12 |
159*159 |
38 |
208 |
4500*1800*2350 |
8800 |
|
JHK-1000GF |
1000 |
1250 |
1800 |
KTA38-G9 |
12 |
159*159 |
38 |
208 |
4500*1800*2350 |
9200 |
|
JHK-1100GF |
1100 |
1375 |
1980 |
KTA50-G3 |
16 |
159*159 |
50 |
205 |
5300*2080*2500 |
10000 |
|
JHK-1200GF |
1200 |
1500 |
2160 |
KTA50-G8 |
16 |
159*159 |
50 |
205 |
5700*2280*2500 |
10500 |
|
JHK-1440GF |
1440 |
1800 |
2592 |
QSK50G7 |
16 |
159*190 |
60 |
205 |
5700*2280*2500 |
12500 |
|
JHK-1680GF |
1680 |
2100 |
3024 |
QSK60G3 |
16 |
159*190 |
60 |
205 |
5700*2280*2500 |
13000 |
|
JHK-1760GF |
1760 |
2200 |
3168 |
QSK60G4 |
16 |
159*190 |
60 |
205 |
5800*2300*2600 |
13500 |
|
JHK-1840GF |
1840 |
2300 |
3312 |
QSK60G13 |
16 |
159*190 |
60 |
205 |
5800*2300*2600 |
13500 |
1. The above technical parameters specify a rotational speed of 1500 RPM, a frequency of 50 Hz, a rated voltage of 400V/230V, a power factor of 0.8, and a connection method of 3-phase 4-wire. The 60Hz generator set can be customized according to the special needs of customers.
2. The generator set can be selected from well-known brands such as Wuxi Stanford, Shanghai Marathon, and Shanghai Hengsheng based on the customer's requirements.
3. This parameter table is for reference only. Any changes will not be notified separately.
