Three-phase Fully Automatic AC Voltage Stabilizer
Short Description:
Main features of MTU diesel generator sets: 1. V-shaped arrangement with a 90° angle, water-cooled four-stroke, exhaust gas turbocharged, and inter-cooled. 2. The 2000 series adopts electronically controlled unit injection, while the 4000 series uses a common rail injection system. 3. Advanced electronic management system (MDEC/ADEC), outstanding ECU alarm function, and a self-diagnostic system capable of detecting over 300 engine fault codes. 4. The 4000 series engines have an automatic cyli...
Properties
| Accuracy of voltage stabilization | 380V±3% | Frequency | 50Hz/60Hz |
| Three-phase input voltage | Phase voltage 160V-250V Wire voltage 277V-430V (other voltages customization available) |
Adjustable time | <1s (when input voltage has a change of 10%) |
| Ambient temperature | -5℃~+40℃ | ||
| Waveform distortion | No additional waveform distortion | ||
| Three-phase output voltage | Phase voltage 220V Wire voltage 380V |
Load power factor | 0.8 |
| Dielectric strength | 1500V/1min | ||
| Insulation resistance | ≥2MΩ |
Type specification
| Type | Spec(KVA) | Product size D×W×H(cm) | Package size D×W×H(cm) | Qty |
| Three-phase four-wire | SVC-3 | 42×38×19 | 60×43×26 | 1 |
| SVC-4.5 | 42×38×19 | 60×43×26 | 1 | |
| SVC-6 | 29.5×32×69 | 38.5×43×76 | 1 | |
| SVC-9 | 35×33×78 | 42×42×86 | 1 | |
| SVC-15 | 43×38×73 | 45.5×44×94 | 1 | |
| SVC-20 | 43×40×80 | 53×50×94.5 | 1 |
| Type | Spec(KVA) | Product size D×W×H(cm) | Package size D×W×H(cm) | Qty |
| Three-phase four-wire | SVC-30 | 50×41.5×90 | 62×54×99 | 1 |
| SVC-40 | 45.5×55.5×115 | 55.5×65.5×125 | 1 | |
| SVC-50 | 45.5×55.5×115 | 55.5×65.5×125 | 1 | |
| SVC-60 | 45.5×55.5×115 | 55.5×65.5×125 | 1 | |
| SVC-80 | 83×76×153 | 95×87×167 | 1 | |
| SVC-100 | 83×76×153 | 95×87×167 | 1 |
